Jenkins
Backhoe
- One Size
Our heavy duty planetary drive augers use 2” hex bits, with 4” through 36” bits available. The drive units come with a 3-year warranty. Our bits are double-flighted with replaceable teeth (Rock bits available upon request). We have 2’, 3’ and 4’ extensions also available. The drive hanger/ QT plate is designed to work like a plumb-bob and so will self-center vertically regardless of the angle of your loader arms. This drive is designed for standard flow machines, from 15-30 gpm. These are fantastically reliable units with only basic maintenance required.
As always, all of our attachments are complete with all necessary hoses, sleeves, cylinders and flat face couplers.
| Maximum Output Torque | 2000 ft/lb |
| Recommended Fluid Flow | 15-20 gpm |
| Recommended Pressure Continuious | 3000 PSI |
| OUTPUT FLOW (GPM) | SPEED (RPM) |
| 10 | 52 |
| 12 | 62 |
| 14 | 73 |
| 16 | 83 |
| 18 | 94 |
| 20 | 104 |
