Seal Bilt
Skid-Max 3X
- 72" | 84"
Our heavy duty planetary drive augers use 2” hex bits, with 4” through 36” bits available. The drive units come with a 3-year warranty. Our bits are double-flighted with replaceable teeth (Rock bits available upon request). We have 2’, 3’ and 4’ extensions also available. The drive hanger/ QT plate is designed to work like a plumb-bob and so will self-center vertically regardless of the angle of your loader arms. This drive is designed for standard flow machines, from 15-30 gpm. These are fantastically reliable units with only basic maintenance required.
As always, all of our attachments are complete with all necessary hoses, sleeves, cylinders and flat face couplers.
Maximum Output Torque | 2000 ft/lb |
Recommended Fluid Flow | 15-20 gpm |
Recommended Pressure Continuious | 3000 PSI |
OUTPUT FLOW (GPM) | SPEED (RPM) |
10 | 52 |
12 | 62 |
14 | 73 |
16 | 83 |
18 | 94 |
20 | 104 |
